Cat5e Punch Down Keystone Jack - White - PrimeCables®

Cat5e Punch Down Keystone Jack, Network RJ45 Female - White

Dual-color coded labeling made for wiring schemes

Cat5e RJ45 keystone jack designed for use with a wall-plate for network wiring installs. Simply insert the leads in the coloring order you wish and clamp them down. Easy to use, modular Cat 5e RJ45 Keystone jack for ethernet. Can be used with keystone wall plates, patch panels, or surface mount boxes.

How to Connect

• Step 1. Strip about 1” off of the outer jacket of the cable. If using Cat6 cable, trim off the spleen so that it doesn’t get in the way of the wires.
• Step 2. Untwist and splay out the wires and sort them through the appropriate slots on the connector. Follow the color coding diagram on the inside of the connector for the proper wiring standard you wish to use.
• Step 3. Place the blade of your punch down tool over each wire and press down firmly until you hear the tool snap. If you are using a cut blade, make sure the cutting tip is on the outside of the connector. The cutting tip will trim away the excess wire automatically. Do this for all 8 wires.
• Step 3b. If you did not use a cutting blade, you’ll need to trim away the excess wires after you have finished punching them down.
• Step 4. Place the wire caps over each set of terminals and press down in place.

Features

• Standard keystone size
• 90 degree wire connection
• Easy to read "Cat 5e" label on face
• 568A and B compliant and UL listed
• Includes clear plastic termination cap
• 110 type IDC punch down connectors
• Color coded wiring diagram next to wire clips
• Can be used with keystone wall plate or patch panel

Note that the width of the RJ45 keystones is such that two cannot be used side-by-side in the same wall-plate.

Note: The color indicated can vary in tone and/or hue between production runs and manufacturing facilities. The color of this item may not be an exact match to any other product, even if they are indicated as being the same color, whether sold by PrimeCables or any other vendor. Individual pieces may also vary very slightly in color from each other.
